Aerial Fiber Optical Cable

● 2 ~ 288 cores

● PE jacket with good   resistance to ultraviolet radiation，the AT jacket can withstand high voltage   induction field strong electric corrosion

● Figure‘8’Self-Supporting optical   cable and ADSS optical cable

● Steel wire/FRP as strength   member.

● Loose-tube twisted single   sheath or central tube structure

● Wrinkled steel belt   armored for non-self-supporting type aerial fiber optical cable

● High tensile steel   strand wire for self-supporting type aerial fiber optical cable

● Loose sleeve material with good   hydrolysis resistance and high strength;

●Compact structure，excellent waterproof performance,   excellent mechanical performance and temperature performance

● Bunched or ribbon fiber

● SM (G.652D, G.655, G.657.A1,   G.657.A2) and MM (OM1, OM2, OM3, OM4) are available;

● PE, LSZH outer jacket   material optional

● AT outer jacket for ADSS

Duct Fiber Optical Cable

● 2 ~ 576 cores

● Steel wire/FRP as strength   member.

● Aluminum tape is more suitable   for piping

● Loose-tube twisted single sheath   or central tube structure

● Loose sleeve material with good   hydrolysis resistance and high strength;

●Compact structure，excellent waterproof performance, excellent   mechanical performance and temperature performance

● Bunched or ribbon fiber

● SM (G.652D, G.655, G.657.A1,   G.657.A2) and MM (OM1, OM2, OM3, OM4) are available;

● PE, AT，LSZH outer jacket material optional

Direct Buried Fiber Cable

● 2 ~ 576 cores

● Steel wire/FRP as strength   member.

● Must be double Jacketed, with at   least one layer of armor.

● Good resistance to lateral   pressure and softness

● Loose-tube twisted single sheath   or central tube structure

● Loose sleeve material with good   hydrolysis resistance and high strength;

●Compact structure，excellent waterproof performance,   excellent mechanical performance and temperature performance

● Bunched or ribbon fiber

● SM (G.652D, G.655, G.657.A1,   G.657.A2) and MM (OM1, OM2, OM3, OM4) are available;

● PE, LSZH outer jacket material   optional

Air Blowing Fiber Optical Cable

● 2 ~ 144 cores

● Non-mental design can prevent the   cable from radio interference and magnetic wave interference

● Specially designed compact   structure is good at preventing loose tubes from shrinking

● Loose tube filling compound   ensure good moisture resistance performance

● Lighter and small diameter

● Excellent flexibility and bending   performance

● High dense fiber packed, small   diameter and light weight; it’s the better option for installation in duct

● SM (G.652D, G.655, G.657.A1,   G.657.A2) and MM(OM1, OM2,OM3,OM4) are available;

● Rapid pipe installation

Submarine Fiber Optical Cable

● 2 ~ 288 cores

● Steel wire as strength member.

● Loose-tube twisted single   sheath structure

● Steel wire armoring

● Applicable for underwater 100   meters

● Loose tube material with   good hydrolysis resistance and high strength; Flooding jelly compound to   ensure critical protection of fiber

●Compact structure，excellent waterproof performance,   excellent mechanical performance and temperature performance

● bunched or ribbon fiber

● SM (G.652D, G.655, G.657.A1,   G.657.A2) and MM(OM1,OM2,OM3,OM4) are available;

● PE，LSZH outer jacket material optional
