Optical fiber patch cords are used to from equipment to optical fiber cabling links. There is a thicker protective layer, which is generally used in the connection between the optical transceiver and the terminal box, and is used in some fields such as optical fiber communication systems, optical fiber access networks, optical fiber data transmission, and local area networks. According to the different uses of optical fiber patch cords, we classify them into several categories, Normal fiber patch cords, CPRI patch cords, MPO patch cords, etc.
Normal Fiber Patch Cords
Patch Cord assemblies are cord-type fiber optical cables terminated with connectors at both end. The type of cable fiber and connector and the length of the patch cords can be freely specified by the customer as shown below. Pigtails are used for terminating fiber optical cables by splicing them the fibers of the cable and connecting the other end, which supplied with a connector to a patch panel or directly to equipment.
|
|
|
|
| Patch Cord Simplex | Patch Cord Armored Duplex | Bunched Patch Cord | FTTH Drop Cord GJXH Simplex |
|
|
|
|
| Fiber Pigtail | Pigtail Colors | Bunched Pigtail | Drop Pigtail GJXH |
Features
● End-Face Type: PC/UPC/APC
● Customer lengths and connectors are available upon request
● Fiber Diameter:9/125; 50/125; 62/125 Available for Simplex and duplex, pigtail type
● Low insertion loss and high return loss, high dense connection, easy for operation
● Fiber Type: Single mode fiber G652D, G657A1 and G657A2, Multimode fiber OM1, OM2, OM3 and OM4 are available
● The outer jacket can be PVC, LSZH, OFNR, OFNP，Armored etc Available for different connectors: SC, LC, FC, ST, MPO/MTP, MTRJ, MU, etc
Applications
● CATV
● Computer networks
● Telecommunication networks
● ODF of optical transmission system
● High speed data transmission network
● High quality graphic transmission network
● Connection of optical transmission equipment
CPRI Patch Cords
The CPRI patch cords are standard size for Duplex LC Connectors, widely used in FTTA, Base station, and the outdoor waterproof condition. SOPTO supplies FTTA(Fiber to the Antenna) DLC (Dual LC Connector) SM GYFJH 2G.657A patch cord for TD-SCDMA,WCDMA,CDMA2000, Wimax, 2G, 3G, 4G and 5G Base Station BBU-RRU outdoor. These products are good for CPRI application.
|
|
|
|
| Armored breakout Type | Waterproof Cover+Armored Type | Waterproof Cover Type | Normal Type |
Features
● The CPRI patch cords are used for outdoor RRU transmitting optical signal and remote fiber feeder etc;
● Standard Duplex LC connector, well connected with standard LC adaptor
● Available Single mode and Multimode
● IP67 protection, salt-mist proof, humidity proof, dust proof
● Low insertion/return loss, steady optical transmitting.
● Light weight, waterproof, dustproof, moisture proof, Metal hard housing.
● 500cycles Mechanical life.
Applications
● Widely used in FTTA & FTTH
● Used for 3G 4G base station
● BBU, RRU, RRH, LTE
MPO Patch Cords
The single-mode and multimode MPO products are multi fiber connectors used in high-density backplane and Printed Circuit Board(PCB) applications in data and telecommunications system. The MPO connector offers up to 12 times the density of standard connectors, providing significant space and cost savings.
MPO patch cord utilize precision molded MT ferrules, with metal guide pins and precise housing dimensions to ensure fiber alignment when mating. The MPO can be mass terminated in combination of 4,8,12 or 24 fibers.
|
|
|
Features
● Precision molded MT ferrule
● High precision guide pins for exact alignment
● Compact design, up to 4,8,12,24 fibers
● IEC 61754-7 Compliant
● Telcordia GR-1435-CORE Compliant
Applications
● Gigabit Ethernet
● Industrial & Military
● Premise Installations
● CATV, Video and Multimedia
● Telecommunication Networks
● Interconnection for O/E modules
● Active Deviced/Transceiver Interface
● Asynchronous Transmission Mode(ATM)
● Optical Switch interframe connections
● Parallel optical interconnect between PC Cards and patch panels
For more detailed information and ordering information of fiber optic patch cords, please contact us. [email protected]
