The transmission mode of light in optical fiber can be divided into: single-mode fiber and multi-mode fiber.
Multi-mode fiber(multi mode fiber): the central glass core is coarser (50 or 62.5μM) and can transmit light in a variety of modes. However, its intermodal dispersion is large, which limits the frequency of transmitting digital signals, and increases more often with distance. For example, 600MB/KM fiber has only 300MB of bandwidth at 2KM. Therefore, multimode fiber transmission distance is relatively close, generally only a few kilometers.
Single mode fiber: the central glass core is thin (the core diameter is typically 8-10?m) and can transmit only one mode of light. therefore, its inter-mode dispersion is very small, suitable for remote communication, but there is still material dispersion and wave guide dispersion, so that the single-mode fiber on the light source spectrum width and stability has higher requirements, that is, the spectral width is narrow, stability is better.
All of Sopto's fiber optic cables can be customized to single mode or multi-mode, and the following are some fiber optic cable classifications owned by Sopto, if you have more questions, please cantact us
SM/MM Indoor Cable
--------------------------------------------------------------------
Type | PN | Description |
GYTA5333 | 2 ~ 288 cores, Outdoor optical cable, Metal strength member; Aluminum-polyethylene adhesive and Steel-polyethylene adhesive inner jacket ;Single smaller round steel wire armoring；PE Outer jacket | |
GYFTY33 | 2 ~ 288 cores, Non-metal strength member, PE inner jacket; Single smaller round steel wire armoring；PE Outer jacket | |
GCYFY | 2 ~ 144 cores, Tiny tube; Semi-dry water-blocking; HDPE jacket | |
GYTA53 | 2 ~ 576 cores, Metal strength member; Aluminum-polyethylene adhesive inner jacket; Steel-polyethylene adhesive outer jacket | |
GYFTA53 | 2 ~ 576 cores, Non-metal strength member, Aluminum-polyethylene adhesive inner jacket; Steel-polyethylene adhesive outer jacket | |
GYFTY53 | 2 ~ 576 cores, Non-metal strength member, PE inner jacket; Steel-PE adhesive outer jacket | |
GYTA | 2 ~ 576 cores, Metal strength member; Aluminum-polyethylene adhesive jacket | |
GYFTY | 2 ~ 576 cores, Outdoor optical cable, Non-metal strength member; PE jacket | |
GYFTC8A53 | 2 ~ 288 cores, Figure ‘8’ Self-Supporting optical cable, Non-metal strength member, Aluminum-polyethylene adhesive inner jacket, Steel-polyethylene adhesive outer jacket | |
ADSS | 2 ~ 288 cores, Single or Double protector All dielectric Self-Supporting optical cable, Non-metal strength member; PE inner jacket; PE outer jacket; 50~100M span | |
GYTC8S | 2 ~ 288 cores, Figure 8’Self-Supporting optical cable, Metal strength member; Steel-polyethylene adhesive jacket |
SM/MM Outdoor Cable
--------------------------------------------------------------------
Type | PN | Description |
GJFJH | Indoor fiber patch cord Cable Aramid yarn strength member; LSZH jacket (1~72 cores) | |
Break-out Cable GJBFJH | Indoor break-out Cable Tight buffer fiber structure; Aramid yarn strength member; water blocking tape; LSZH jacket (2~72 cores) | |
GJXFH | 1 ~ 72 cores, Indoor Cabling Bow-Type Drop Cable, Non-metal strength member KFRP; LSZH jacket; Non-Self-Supporting | |
GJXH | 1 ~ 72 cores, Indoor Cabling Bow-Type Drop Cable, Metal strength member; LSZH jacket; Non-Self-Supporting | |
GJYXCH | 1 ~ 72 cores, Outdoor Cabling Bow-Type Drop Cable, Metal strength member; LSZH jacket; Self-Supporting | |
GJYXDCH | Outdoor Cabling Bow-Type Drop Cable , Optical fiber ribbon，Metal strength member ; LSZH jacket; Self-Supporting |
Product Certificate
Sopto fiber optic cable took the first lead to pass the ISO9001 quality system,ISO14001 environment management system,
OHSAS18001 occupational health safety management system，and its fiber optical cable meet
the requirements of European CE, RoHs, Chinese TLC
Packaging & Shipping
Transaction Process
Sopto can provide Outdoor Fiber Optical Cables , Indoor Fiber Optical Cables , FTTH Cables , If you want to know more about the exact information of the specified fiber optical cable, Please contact us.
