  • 96 cores-144 cores FDU 96 cores-144 cores FDU 96 cores-144 cores FDU
  • 96 cores-144 cores FDU

    The fiber distribution unit box is a high-capacity, high-density fiber distribution frame, which is suitable for the composition and distribution of optical fibers in the fiber access network, and realizes the connection, distribution and scheduling of the optical fiber lines.
  • Contact Us
  • ● Optional aluminum or cold rolled sheet, high strength, corrosion resistant, lightweight, easy to install and transport

    ● Standard 19-inch structure, could be installed on various of standard racks.

    ● Electrostatic spraying in the whole surface, nice appearance.

    ● The adapter panel can be flexibly flipped and the Splice fiber operation is convenient

    ● Capacity can be flexibly customized as required and Maximum capacity can be made 144 cores

    ● Modular structure for in stored, splice and organizes cable.

    ● Built-in direct melt unit capable of providing direct connection functionality

    ● With secure and reliable fastening and grounding protection devices for the optic fiber

    ● Applicable to strap-shaped and non-strap shaped fibers, and inserting installation of SC, FC, ST (additional flange) adapters


    ● Telecommunication subscriber loop

    ● Fiber to the home (FTTH)

    ● LAN/WAN


    Part Number

    Product Description

    Size(mm)

    SPDF-I96SCU-FMM1

    ODF Unit Box Indoor 96 cores without door Simplex SC/Duplex LC type without adaptor, pigtail and splitter Metal customized type

    482(W)*200(D)*215(H)

    SPDF-I96SCU-FAM1

    ODF Unit Box Indoor 96 cores without door Simplex SC/Duplex LC type without adaptor, pigtail and splitter AL customized type

    482(W)*200(D)*215(H)

    SPDF-I120SCU-FMM1

    ODF Unit Box Indoor 120cores without door Simplex SC/Duplex LC type without adaptor, pigtail and  splitter Metal customized type

    482(W)*396(D)*130(H)

    SPDF-I120SCU-FAM1

    ODF Unit Box Indoor 120cores without door Simplex SC/Duplex LC type without adaptor, pigtail and splitter AL customized type

    482(W)*396(D)*130(H)

    SPDF-I144SCU-FMM1

    ODF Unit Box Indoor 120cores without door Simplex SC/Duplex LC type without adaptor, pigtail and splitter Metal customized type

    482(W)*396(D)*130(H)

    SPDF-I144SCU-FAM1

    ODF Unit Box Indoor 120cores without door Simplex SC/Duplex LC type without adaptor, pigtail and splitter AL customized type

    482(W)*396(D)*130(H)
