The single-mode and multimode MPO products are multi fiber connectors used in high-density backplane and Printed Circuit Board(PCB) applications in data and telecommunications system. The MPO connector offers up to 12 times the density of standard connectors, providing significant space and cost savings.
MPO patch cord utilize precision molded MT ferrules, with metal guide pins and precise housing dimensions to ensure fiber alignment when mating. The MPO can be mass terminated in combination of 4,8,12 or 24 fibers.
Features:
● Precision molded MT ferrule
● High precision guide pins for exact alignment
● Compact design, up to 4,8,12,24 fibers
● IEC 61754-7 Compliant
● Telcordia GR-1435-CORE Compliant
Applications
● Gigabit Ethernet
● Industrial & Military
● Premise Installations
● CATV, Video and Multimedia
● Telecommunication Networks
● Interconnection for O/E modules
● Active Deviced/Transceiver Interface
● Asynchronous Transmission Mode(ATM)
● Optical Switch interframe connections
● Parallel optical interconnect between PC Cards and patch panels
Sopto can provide you full range of the MTP/MPO cables. If there is any needs, then please do not hesitate to send us your inquiry, Email:[email protected].
