LAN cable can be used for network connections,cabling System network wiring project, equipment or horizontal subsystem termination, port connection with modular jumper wire system equipment, such as: connection and wireless telecom broadband ADSL MODEM router, routers, switches, hubs, firewalls between devices such as the LAN interface of the computer network card interface, etc.
Features
● LAN cable Cat6a is made of high quality and environmentally friendly LSZH Jacket , excellent tensile strength, environmental protection, wear resistance and oxidation resistance.
● Low resistance, no oxygen copper conductor core, can support up to 10G Ethernet transmission speed, faster and more stable.
● PE insulation materials, with good electrical insulation and corrosion resistance, make the products more durable.
● The RJ-45 plug is designed with 50 mm gilt, with good contact and transmission properties, oxidation resistance, rust, and no blackening.
● Meet the requirements of TIA/EIA-568B or TIA 568A.
Application
● Network wiring engineering
● LAN wiring
● Family、Internet Bar
Technical Data
Item | Parameter |
Type | CAT6A |
Jacket Material | LSZH |
Jacket Color | Optional |
Length | Optional |
Transmission Distance | 100m |
Conductor Diameter | 24AWG |
Line Sequence | Standard TIA/EIA - 568 - B |
Shielding Type | UTP |
Working Temperature | -20~60℃(-4~140℉) |
Data Rate | 1000Mbps |
Band Width | 500MHz |
If you need to know more about lan cable, please contact us
Tags:Lan cable,cat6a UTP,Network Cable
