As a manufacturer of optical modules for data centers,sopto offers optical modules with different wavelength to meet the different needs of our customers, and we also accept customized services. All optical transceivers are RoHS compliant and could be 100% compatible with branding equipment, such as Cisco, Extreme, Juniper, HP, H3C, Linksys etc
The following are common models, if you hace moere requirements, please contact us
PN | Data Rate(Gbps) | Distance | Output Power(dBm) | Sensitivity(dBm) | Interface | DDM |
1310nm | ||||||
SPT-PB3503-L(S)40D | 155M | 40km | -9~-3 | -34 | Simplex LC/SC | D |
SPT-FB351G-L(S)20D | 1.25 | 20km | -9~-3 | -24 | Simplex LC/SC | D |
SPT-P131G-20D | 1.25 | 20km | -9~-3 | -24 | Duplex LC | D |
SPT-P856G-S3D | 8.5 | 300m/OM3 | -5~-1 | -11 | Duplex LC | D |
SFP-P136G-10D | 8.5 | 10km | -5~0 | -15 | Duplex LC | D |
SPT-P13TG-LR | 9.95~11.3 | 10km | -8.2~0.5 | -14.5 | Duplex LC | D |
SPT-P55TG-ER | 9.95~11.3 | 40km | 0~3 | -17 | Duplex LC | D |
1550nm | ||||||
SPT-PB351G-L(S)20D | 1.25 | 20km | -9~-3 | -24 | Simplex LC/SC | D |
SPT-PB3503-L(S)40D | 155M | 40km | -9~-3 | -34 | Simplex LC/SC | D |
SPT-P55TG-ER | 9.95~11.3 | 40km | 0~3 | -17 | Duplex LC | D |
850nm | ||||||
SPT-P856G-S3D | 8.5 | 300m/OM3 | -5~-1 | -11 | Duplex LC | D |
SPT-P85TG-SR | 9.95~11.3 | 300m/OM3 | -5~-1 | -11 | Duplex LC | D |
