Is an MTP connector compatible with an MPO connector?
The MTP connector is in complete compliance with all MPO connector standards including the EIA/TIA-604-5 FOCIS 5 and the IEC-61754-7. The MTP connector is inter-matable with all generic MPO-style connectors that are compliant to these industry standards. Generic MPO connectors are limited in performance and are not able to offer the high performance levels of the US Conec MTP connector.
MTP vs MPO, why is an MTP connector better than a generic MPO connector?
The MTP has elliptical shaped guide pins that reduce ferrule wear. Generic MPO connectors have chamfered shaped guide pins. Unlike single fiber connectors, the adapters for MPO-style connectors are just for coarse alignment. The elliptical shape does not chip the ferrule material like a MPO's chamfered guide pins. The MTP guide pin shapes serve to reduce the amount of debris that can fall into the guide pin holes or on the ferrule end face.
What makes the MTP connector superior to generic MPO connectors?
The MTP connector has features and benefits that are not available on generic MPO connectors. Some of the key distinctions include:
1. The MTP connector housing is removable. This feature allows the customer to:
● Re-work and re-polish the MT ferrule
● Change the gender after assembly or even in the field
● Scan the ferrule interferometrically after assembly
2. The MTP connector offers ferrule float to improve mechanical performance. This allows two mated ferruled to maintain physical contact while under an applied load. (US Patent 6,085,003)
3. The MTP connector uses tightly held tolerance stainless steel guide pin tips with an elliptical shape. The elliptical shaped guide pin tips improves guidance and reduces guide hole wear. (US Patent 6,886,988)
4. The MTP connector has a metal pin clamp with features for centering the push spring. This feature:
● Eliminates lost pins
● Centers spring force
● Eliminates fiber damage from spring
5. The MTP connector spring design maximizes ribbon clearance for twelve fiber and multifiber ribbon applications to prevent fiber damage.
6. The MTP connector is offered with four standard variations of strain relief boots to meet a wide array of applications.
● Round, Loose Fiber Cable Constructions
● Oval Jacketed Cable
● Bare Ribbon Fiber
● Short boot which reduces the footprint by 45%. Ideal for use in space limited applications.
